Portfolio
at a glance

The control valve is the most important piece of equipment in modern process loops and control systems.



The operational conditions of fluid pressure, temperature and process dynamics require rigor in the analysis of intrinsic characteristics and in the selection of control valves to obtain efficient performance in a process control system.



We have assembled a range of products with the design, geometry and shapes that differentiate us in the specialty and severe service control valve market, in applications, such as: superheated steam, high differential pressures, volatile, corrosive, dirty and erosive fluids, as well as solutions to eliminate cavitation and aerodynamic noise issues.



These shape and design characteristics, together with the use of noble materials, modern casting processes and advanced assembly and test technology, has allowed us to achieve an extraordinary level of capability and quality that is recognized by our Customers all over the world.



The control valve offering includes Reciprocating Globe, Angle and Three-Way, Rotary Eccentric Plug, Double and Triple Offset Butterfly, Segmented V-Ball, Specialty Ball, Desuperheaters and Regulators. They come equipped with Double-acting spring return actuators and advanced digital positioners and provide the thrust, speed, accuracy and response to handle the most exacting applications.

GLS

The GLS Series is the work-horse of the reciprocating valve offering with a modern design that incorporates an advanced clamped-in seat ring and a double upper guide system. It is available in a wide range of configurations and suitable for a wide variety of applications in the continuous process industries. Its double-acting spring-cylinder actuator ensures high actuation thrusts, pneumatic stiffness and excellent performance levels. The GLS series is extremely versatile and can be supplied with several options to meet the specific needs of each application.



TECHNICAL FEATURES



GXL General Service

Integrated system with valve, actuator and digital positioner, versatile, robust and simple, compact and lightweight, high flow Cv coefficients, low emission packing, micro flow design available, high performance and fast delivery, general service & utilities.



TECHNICAL FEATURES



GLH High Performance

Versatile configurations: single seat, cage, angle, 3-ways, steam jacketed, cryogenic, low noise anticavitation, reduced trims. Double top-stem guiding designed out of stream and large stem diameter ensures shutoff and no galling or sticking, simple to service and maintain



TECHNICAL FEATURES

GLB Bar Stock

Globe and Angle configuration, extremely wear resistant, can meet any custom face to face requirements



TECHNICAL FEATURES

GLE Erosive Application

Specially designed for severe, flashing and erosive service, slurry fluids



TECHNICAL FEATURES

GLA Y Type

“Y” type body, greater flow rate capacity per size, streamlined flow path, almost straight passage area creates less turbulence through the valve and piping



TECHNICAL FEATURES

GLC Cryogenic

Top entry design, light weight body, leakage Class VI, suitable down to -218°C (-360°F)



TECHNICAL FEATURES

Alpha

In applications with low and medium intensity cavitation, Alpha trim offers an economical and effective solution to minimize the harmful effects of this condition. The cage trim flow to close design, with staggered and diametrically opposed holes, directs the fluid jets towards the center of the trim and away from metal surfaces. The use of hardened materials limits damage and erosion phenomena.



TECHNICAL FEATURES

Attenuator plate Beta

Using the same principle as the Beta Trim, the Beta attenuator plate is installed downstream of the control valve to reduce overall noise levels on gas applications. Each plate can be designed with up to four drilled-hole stages, providing noise reductions of up to 15 dBA (depending upon the process conditions). The Beta attenuator can be used for liquid flows when a higher counter pressure on valve trim is required to avoid cavitation.



TECHNICAL FEATURES

Delta

Delta is a Multistep-multipath concept trim. Delta effectively reduces the noise produced by gases and liquids and eliminates the effects of cavitation. The cartridge comprises a disk stack with engineered grooves, which forces a series of expansions, contractions and turns of the fluid, thus reducing the pressure gradually.



TECHNICAL FEATURES

Beta

Valves equipped with Beta Trim reduce noise levels in gas applications up to 20 dBA. The trim design incorporates a series of holes in concentric silencers that allows the pressure reduction and gas expansion in stages; which controls velocity and minimizes downstream noise.



TECHNICAL FEATURES

Gamma

Gamma trim eliminates the damage caused by cavitation and minimizes hydrodynamic noise even under the most severe liquid applications. The Gamma cartridge is designed to take the total pressure drop through the valve trim in stages, and avoid cavitation throughout the entire path of the fluid in the trim.



TECHNICAL FEATURES

Omicron

Omicron multistep trim prevents damage caused by cavitation, and is applied when applications incur high differential pressures and very low flow rates. The plug head has grooves that extend spirally along its length and intersect several times. The fluid passing through the channels experiences a continuous increase in the passage area, and pressure reduction occurs in stages.



TECHNICAL FEATURES

Omega

Omega internal trim is designed for applications with liquids experiencing extreme cavitation and low flow rates. Based on the same principles as Gamma internal trim, Omega trim utilizes an internal cartridge containing channels and orifices which is part of the seat-guided plug. The perforated cartridge may contain up to 5 stages for the gradual reduction of pressure. The operating fluid should be clean and free of particles.



TECHNICAL FEATURES

EXL Eccentric Plug

High Cv capacity, non-crossover shaft, std. anti blow-out proof stem, class IV and VI shut – off, NACE noise attenuator available



TECHNICAL FEATURES

VXL Segmented Ball

V-notch Ball, high rangeability bidirectional seat, non-crossover shaft, class IV and VI shut-off



TECHNICAL FEATURES

BXL Double Eccentric Butterfly

Double offset configuration, leakage class IV, V and VI, bi- metallic seal ring for bidirectional flow, cryogenic design, drilled wing design for anti cavitation or noise reduction available



TECHNICAL FEATURES

AJ Triple Offset Metal Seated

Unique triple offset, quarter turn geometry for non-rubbing design, design meets API 609, ASME B16.34, EN 12516, EN 593, resilient metal sealing and torque seating for zero leakage tightness performance (tested to API 598), Stellite® gr. 21 overlay on seat for extended valve service life on a wide range of applications, all-metal construction for inherently fire safe valve design, blow-out proof stem as per API 609 requirements



TECHNICAL FEATURES

HXL High Pressure

Side entry split body, trunnion design, high flow capacity, high rangeability, accurate control capability, class V and VI sealing capability, noise reduction on gas, anti cavitation on liquid, compatible with dirty fluids



TECHNICAL FEATURES

RA-TL Scotch Yoke

Disengaging handwheel, limit stops, positioners, solenoids, limit switches, others



TECHNICAL FEATURES

LA-XL Linear Spring Piston

Disengaging handwheel, limit stops, positioners, solenoids, limit switches, others



TECHNICAL FEATURES

RA-XL Rotary Spring Piston

Top mounted push only handwheel, side mounted or top mounted continuosly connected handwheel, limit stops, positioners, solenoids, limit switches, others



TECHNICAL FEATURES

LA-ES Heavy Duty Spring Piston

Disengaging handwheel, limit stops, positioners, solenoids, limit switches



TECHNICAL FEATURES

DVP Variable Area

High rangeability, good water atomization also at minimum flow variety of size of spray nozzle sizes, accurate control capability, minimun dimension thanks to built-in control system, available for cryogenic application, high differential pressure allowed, with multistage trim design



TECHNICAL FEATURES

DSP Spring Assisted Probe

Easy and versatile design, no practical limitations in flow rate and operating conditions, no upper limitations in pipe size, with multiple nozzle layout



TECHNICAL FEATURES

DSE Spring Assisted External Mounting

A variety of nozzle dimensions available, no practical limitations in flow rate and operating conditions, no upper limitations in pipe size, with multiple nozzle layout, internal protection linear available, water distribution piping designed with free expanding design



TECHNICAL FEATURES

DVT Ventury Type

Good atomization even with very low steam velocity, suitable for very low flow rate



TECHNICAL FEATURES

SAR Self Actuated - Pressure Reducing

Direct operated pressure reducing valve, high rangeability, several membrane materials available, cryogenic design



TECHNICAL FEATURES

SAB Self Actuated - Backpressure

Direct operated pressure relief, backpressure valve, high rangeability, several membrane materials available, cryogenic design



TECHNICAL FEATURES

SAS Self Actuated Spring Pressure

Direct operated spring pressure regulator, high rangeability, several membrane materials available, low and high temperature design



TECHNICAL FEATURES

SAP Pilot Operated

Pilot operated regulators, low minimum regulating pressure, several membrane materials available, single or double seat design



TECHNICAL FEATURES

Chronos Digital Positioner

Better accuracy and value than E/P positioner, auto calibration and auto tuning functions, locally programmable without opening the device, as well as using HART portable calibrator or computer, large backlit display, single-acting and double-acting capability, 2-stage relay provides fast PID response, RFI & EMI immune, accessories included, adaptive technology to achieve condition fast and easy set-up.

TECHNICAL FEATURES

DOWNLOAD BROCHURE
