Portfolio
at a glance

The control valve is the most important piece of equipment in modern process loops and control systems.



The operational conditions of fluid pressure, temperature and process dynamics require rigor in the analysis of intrinsic characteristics and in the selection of control valves to obtain efficient performance in a process control system.



We have assembled a range of products with the design, geometry and shapes that differentiate us in the specialty and severe service control valve market, in applications, such as: superheated steam, high differential pressures, volatile, corrosive, dirty and erosive fluids, as well as solutions to eliminate cavitation and aerodynamic noise issues.



These shape and design characteristics, together with the use of noble materials, modern casting processes and advanced assembly and test technology, has allowed us to achieve an extraordinary level of capability and quality that is recognized by our Customers all over the world.



The control valve offering includes Reciprocating Globe, Angle and Three-Way, Rotary Eccentric Plug, Double and Triple Offset Butterfly, Segmented V-Ball, Specialty Ball, Desuperheaters and Regulators. They come equipped with Double-acting spring return actuators and advanced digital positioners and provide the thrust, speed, accuracy and response to handle the most exacting applications.

Reciprocating
Control Valves

Globe control Valves
The G-Stream is the work-horse of the reciprocating valve offering with a modern design that incorporates an advanced clamped-in seat ring and a double upper guide system. It is available in a wide range of configurations and suitable for a wide variety of applications in the continuous process industries. Its double-acting spring-cylinder actuator ensures high actuation thrusts, pneumatic stiffness and excellent performance levels. The G-Stream is extremely versatile and can be supplied with several options to meet the specific needs of each application.

TECHNICAL FEATURES



Integrated system with valve, actuator and digital positioner, versatile, robust and simple, compact and lightweight, high flow Cv coefficients, low emission packing, micro flow design available, high performance and fast delivery, general service & utilities.

TECHNICAL FEATURES



Versatile configurations: single seat, cage, angle, 3-ways, steam jacketed, cryogenic, low noise anticavitation, reduced trims. Double top-stem guiding designed out of stream and large stem diameter ensures shutoff and no galling or sticking, simple to service and maintain

TECHNICAL FEATURES



Globe and Angle configuration, extremely wear resistant, can meet any custom face to face requirements

TECHNICAL FEATURES



Specially designed for severe, flashing and erosive service, slurry fluids

TECHNICAL FEATURES



“Y” type body, greater flow rate capacity per size, streamlined flow path, almost straight passage area creates less turbulence through the valve and piping

TECHNICAL FEATURES



Top entry design, light weight body, leakage Class VI, suitable down to -218°C (-360°F)

TECHNICAL FEATURES

Trim
Options

Alpha
In applications with low and medium intensity cavitation, Alpha trim offers an economical and effective solution to minimize the harmful effects of this condition. The cage trim flow to close design, with staggered and diametrically opposed holes, directs the fluid jets towards the center of the trim and away from metal surfaces. The use of hardened materials limits damage and erosion phenomena.



TECHNICAL FEATURES
Attenuator plate Beta
Using the same principle as the Beta Trim, the Beta attenuator plate is installed downstream of the control valve to reduce overall noise levels on gas applications. Each plate can be designed with up to four drilled-hole stages, providing noise reductions of up to 15 dBA (depending upon the process conditions). The Beta attenuator can be used for liquid flows when a higher counter pressure on valve trim is required to avoid cavitation.



TECHNICAL FEATURES
Delta
Delta is a Multistep-multipath concept trim. Delta effectively reduces the noise produced by gases and liquids and eliminates the effects of cavitation. The cartridge comprises a disk stack with engineered grooves, which forces a series of expansions, contractions and turns of the fluid, thus reducing the pressure gradually.



TECHNICAL FEATURES
Beta
Valves equipped with Beta Trim reduce noise levels in gas applications up to 20 dBA. The trim design incorporates a series of holes in concentric silencers that allows the pressure reduction and gas expansion in stages; which controls velocity and minimizes downstream noise.



TECHNICAL FEATURES
Gamma
Gamma trim eliminates the damage caused by cavitation and minimizes hydrodynamic noise even under the most severe liquid applications. The Gamma cartridge is designed to take the total pressure drop through the valve trim in stages, and avoid cavitation throughout the entire path of the fluid in the trim.



TECHNICAL FEATURES
Omicron
Omicron multistep trim prevents damage caused by cavitation, and is applied when applications incur high differential pressures and very low flow rates. The plug head has grooves that extend spirally along its length and intersect several times. The fluid passing through the channels experiences a continuous increase in the passage area, and pressure reduction occurs in stages.



TECHNICAL FEATURES
Omega
Omega internal trim is designed for applications with liquids experiencing extreme cavitation and low flow rates. Based on the same principles as Gamma internal trim, Omega trim utilizes an internal cartridge containing channels and orifices which is part of the seat-guided plug. The perforated cartridge may contain up to 5 stages for the gradual reduction of pressure. The operating fluid should be clean and free of particles.



TECHNICAL FEATURES

Rotary
Control Valves

EX-Plug
High Cv capacity, non-crossover shaft, std. anti blow-out proof stem, class IV and VI shut – off, NACE noise attenuator available



TECHNICAL FEATURES
V-Shape
V-notch Ball, high rangeability bidirectional seat, non-crossover shaft, class IV and VI shut-off



TECHNICAL FEATURES
B-Disc
Double offset configuration, leakage class IV, V and VI, bi- metallic seal ring for bidirectional flow, cryogenic design, drilled wing design for anti cavitation or noise reduction available



TECHNICAL FEATURES
AJ Triple Offset Metal Seated
Unique triple offset, quarter turn geometry for non-rubbing design, design meets API 609, ASME B16.34, EN 12516, EN 593, resilient metal sealing and torque seating for zero leakage tightness performance (tested to API 598), Stellite® gr. 21 overlay on seat for extended valve service life on a wide range of applications, all-metal construction for inherently fire safe valve design, blow-out proof stem as per API 609 requirements



TECHNICAL FEATURES
HXL
Side entry split body, trunnion design, high flow capacity, high rangeability, accurate control capability, class V and VI sealing capability, noise reduction on gas, anti cavitation on liquid, compatible with dirty fluids



TECHNICAL FEATURES

Pneumatic
Actuators

L-Act
Disengaging handwheel, limit stops, positioners, solenoids, limit switches, others



TECHNICAL FEATURES





Disengaging handwheel, limit stops, positioners, solenoids, limit switches



TECHNICAL FEATURES
R-Act
Top mounted push only handwheel, side mounted or top mounted continuosly connected handwheel, limit stops, positioners, solenoids, limit switches, others



TECHNICAL FEATURES

Desuperheaters
Systems

DVP Variable Area
High rangeability, good water atomization also at minimum flow variety of size of spray nozzle sizes, accurate control capability, minimun dimension thanks to built-in control system, available for cryogenic application, high differential pressure allowed, with multistage trim design



TECHNICAL FEATURES
DSP Spring Assisted Probe
Easy and versatile design, no practical limitations in flow rate and operating conditions, no upper limitations in pipe size, with multiple nozzle layout



TECHNICAL FEATURES
DSE Spring Assisted External Mounting
A variety of nozzle dimensions available, no practical limitations in flow rate and operating conditions, no upper limitations in pipe size, with multiple nozzle layout, internal protection linear available, water distribution piping designed with free expanding design



TECHNICAL FEATURES
DVT Ventury Type
Good atomization even with very low steam velocity, suitable for very low flow rate



TECHNICAL FEATURES

Regulators
Self & Pilot

SAR Self Actuated - Pressure Reducing
Direct operated pressure reducing valve, high rangeability, several membrane materials available, cryogenic design



TECHNICAL FEATURES
SAB Self Actuated - Backpressure
Direct operated pressure relief, backpressure valve, high rangeability, several membrane materials available, cryogenic design



TECHNICAL FEATURES
SAS Self Actuated Spring Pressure
Direct operated spring pressure regulator, high rangeability, several membrane materials available, low and high temperature design



TECHNICAL FEATURES
SAP Pilot Operated
Pilot operated regulators, low minimum regulating pressure, several membrane materials available, single or double seat design



TECHNICAL FEATURES
